Crown Endless Reducer Size 75 Flange PAM 200/24 - Motor housing 90 B5
Crown Endless Reducer Size 75 Flange PAM 200/24 - Motor housing 90 B5
Crown Endless Reducer Size 75 Flange PAM 200/24 - Motor housing 90 B5
Crown Endless Reducer Size 75 Flange PAM 200/24 - Motor housing 90 B5

Crown Endless Reducer Size 75 Flange PAM 200/24 - Motor housing 90 B5

€183.00 Tax included

€151.24 tax excl.

With hollow output shaft of Ø28mm, and input flange PAM 200/24 (Ø Ext 200mm and Ø Input shaft 24mm) type B5, suitable for motors with housing size 90.

Reduction ratios: 7,5-10-15-20-25-30-40.

The powers of the usual engines at 1500 rpm are:

  • 1.5CV Max. net. i=40.
  • 2CV Max. net. i=30.
  • 3CV Reduced housing. Max. net. i=15.
Reduction ratio
  • 7.5
  • 10
  • 15
  • 20
  • 25
  • 30
  • 40

No queries yet, leave the first!


Endless reducer crown size 75,compact execution and high performance, with hollow output shaft of 28mm and input shaft of 24mm.

This reducer size supports motors with flange B5 size 90, this flange size has an OExterior of 200mm and the reducer has an input shaft diameter of 24mm., PAM 200/24

Dimensiones brida entrada reductor sinfin corona

  • Q: 200mm.
  • M: 165mm.
  • N: 130mm.
  • D: 24mm.

Engine power at 1500 rpm commonly used for this type of gearbox and with higher service factor fs≥1 are:

  • 1.5CV 1500rpm. Maximum reduction I-40.
  • 2CV 1500rpm. Maximum reduction I-30.
  • 3CV 1500rpm. Reduced housing. Maximum reduction I-15.

The reduction ratios (i) available are from 7.5 to 40, depending on the input revolutions we can get the following revolutions on the output axis shown in the following table.

Tabla de revoluciones de salida reductores

Dimensiones reductor tamaño 75

You can download all the dimensions of the reducer by clicking on the "DOWNLOADS" tab.
