Endless crown reducer size. 30 63B14
Endless crown reducer size. 30 63B14

Endless crown reducer Size 63 Flange PAM 200/24 - Motor housing 90 B5

€140.63 Tax included

€116.22 tax excl.

With hollow output shaft of Ø25mm, and input flange PAM 200/24 (Ø Ext 200mm and Ø Input shaft 24mm) type B5, suitable for motors with housing size 90.

Reduction ratios: 10-15-20-25-30.

The powers of the usual engines at 1500 rpm are:

  • 1.5CV Max. net. i=30.
  • 2CV Max. net. i=20.
Reduction ratio
  • 10
  • 15
  • 20
  • 25
  • 30

No queries yet, leave the first!


Endless reducer crown of size 63, compact execution and high performance, with hollow output shaft of Ø25mm and input shaft of Ø24mm.

This reducer size supports B5 flange motors size 90, this flange size has an outer Ø of 200mm and the reducer has an inlet shaft diameter of 24mm., PAM 200/24.

Dimensiones brida entrada reductor sinfin corona

  • P: 200mm.
  • M: 165mm.
  • N: 130mm.
  • D: Ø24mm.

The powers of the motors at 1500 rpm usually used for this type of reducers and with higher service factor fs≥1 are:

  • 1.5CV 1500rpm. Maximum reduction I = 30.
  • 2CV 1500rpm. Maximum reduction I = 20.

The reduction ratios (i) available are from 10 to 30, depending on the input revolutions we can obtain the following revolutions on the output axis shown in the following table.

Tabla de revoluciones de salida reductores

Dimensiones reductores tamaño 63

You can download all the dimensions of the reducer by clicking on the "ATTACHMENTS" tab.
