Compact valve for fluids 1/2 NC with pneumatic actuator Fluxa series - Aignep

Compact valve for fluids 1/2 NC with pneumatic actuator Fluxa series - Aignep

€69.18 Tax included

€57.17 tax excl.

Compact seat valve, with simple acting pneumatic actuator , diameter 35mm, and normally closed (NC), with 1/2 thread. Together at FKM. The actuator body is made of anodized aluminum alloy and is pneumatically actuated. The valve is made of brass.

Reference: 51012


Screenshot 2024-02-08 115649

Aignep logo
Representative image for illustrative purposes, the item supplied will correspond to the indicated specifications.

No queries yet, leave the first!
Privacy
Shipments
Returns

Compact, 2- way , 2-position monostable seat valve, with simple acting pneumatic actuator and normally closed (NC), with 1/2 thread. FKM joints which allow it to work with a maximum fluid temperature of 100ºC.

The actuating cylinder is made of aluminum alloy and the stem is made of AISI 304 stainless steel. The valve body is made of brass, size PN16 and with FKM gaskets. It has a mechanical device that indicates the status of the valve, whether it is activated or not.

Technical characteristics:
  • Manufacturer: Aignep
  • Reference: 51012
  • Thread: 1/2"
  • Function: 2/2 NC
  • Diameter of pneumatic actuator : 35mm.
  • Type of action: Simple effect
  • Pilot pressure: 4.5-8 bar
  • Ambient temperature: -20ºC .. +60ºC
  • Working pressure: 16 bar
  • Gasket material: PTFE
  • Fluid temperature: +100ºC
  • Pilot fluid type: Air and inert gas
  • Nominal diameter (DN): 15mm
  • kv: 1.3 m3/h
  • Pressure differential: 15.3 bar maximum (*)
Note: This valve is not suitable for water.

Fluxa Adajusa Aignep series valve dimensions
Table of dimensions for Fluxa Adajusa Aignep series valves

For more information you can download the technical sheet by clicking on the "Attachments" tab.
Material for professional use, install in compliance with the regulations in force at the installation site.
