Transformer 2000VA E:400V S:230V IP-00

€220.90 Tax included

€179.59 tax excl.

Single-phase switching transformer for command, control, and general uses, with an input voltage of 400 Vac and an output voltage of 230 Vac. The transformer has a power output of 2000 VA and an IP00 protection rating.

Reference: TA002205400

transformer symbol 230-230

Representative image for illustrative purposes, the item supplied will correspond to the specifications indicated.

No queries yet, leave the first!
Privacy
Shipments
Returns


Single-phase transformer with 400Vac input and 230Vac output, 2000VA power. Varnished transformer with IP00 protection. Maximum current supplied is 8.70A (apparent current).

The main application of this type of transformer is for command and control in industrial automation systems and for general applications. They are designed to power electrical devices where galvanic isolation between circuits is required. They are protected against moisture by resin impregnation.

These types of transformers are fully reversible.

Technical characteristics of the transformer:

  • Reference: TA002205400
  • Transformer type: Single-phase
  • Primary voltage: 400Vac
  • Secondary voltage: 230Vac
  • Nominal power: 2000VA
  • Maximum intensity in the secondary (In): 8.70A
  • Frequency: 50/60 Hz
  • Dielectric strength between primary and secondary: 4600V
  • Dielectric strength between primary and ground: 3500V
  • Winding: copper wire, class H. Primary and secondary separated (galvanic separation)
  • Protection level: IP00
  • Protection class: I
  • Insulation class: Tª 40ºC/F
  • Connection: Screw-fastener terminals
  • Weight: 15.8kg
  • Transformer encapsulation: Varnished
  • Mounting: By screws or DIN rail fixing
  • Regulation: EN-61558-2-4
DIMENSIONS_TA SERIES 400V-230V


The transformer is supplied without any type of overload protection; it is mandatory to install them to avoid overloading the transformer.

The power and current indicated are apparent, the active current provided by the transformer will depend on the power factor of the connected load.



Professional use material, install in compliance with the regulations in force at the place of installation.
