8000VA 230/400Vac IP-00 single-phase autotransformer
8000VA 230/400Vac IP-00 single-phase autotransformer

Single-phase autotransformer 8000VA 230/400Vac IP-00

Special manufacturing material
€360.27 Tax included

292.9 tax excl.

AT2 8000

autotransformer reversible single-phase of 8000VA, allows the adaptation of voltage between 230 and 400Vac.

It allows to adapt the tension in small machinery and cabinets for automatisms in an economical way.

Reference: AT2-8000

Esquema eléctrico de autotransformador monofásico

1 question about the product
Privacy
Shipments
Returns


autotransformer single-phase for voltage change, reversible, intended for voltage change. They are indicated when it is necessary to adapt the voltage from 230 to 400v / 400 to 230Vac, in an economical way, without galvanic separation. Its usual field of application is used in small machinery and automatisms.

Manufactured with low loss magnetic sheet and copper wire windings, providing high performance.

Specifications:

  • Ref: AT2-8000
  • Transformation ratio: 230/400Vac
  • Power: 8000VA.
  • Frequency: 50/60Hz.
  • Windings: Thermal class N 200ºC.
  • Test voltage: 3KV between mass.
  • Insulators: Thermal class F 155ºC AND H 180ºC.
  • Protection: IP-00.
  • Ambient temperature: TA=25ºC.
  • Cooling: ANAN ( natural Air).
  • Certificate: UNE-EN 61558.

Questions

Question
Hola, tengo varias dudas sobre los autotrafos monofásicos. ¿Cuál es la potencia consumida por un autotrafo cuando no hay carga en el secundario? Si el primario esta protegido por un interruptor diferencial, ¿debe el secundario protegerse con otro diferencial adicional? ¿podrían enviarme algún esquema en el que se vea como conectar primario / secundario y carga? Muchas gracias de antemano.
Answer
Buenos días.

El dato del consumo en vacio de un transformador no nos lo proporciona el fabricante,  así mismo, recomienda la utilización a la salida de un elemnto de corte que esté en función de la intensida máxima que puede soportar para que en el caso de sobrecarga, este elemtno lo detencte y corte. Hay esquema de conexión en las características de los transformadores. El fabricante recomienda sobredimensionar un 20 % sobre la carga máxima a la que tenga que ser sometido.

Saludos

Adajusa
Angel Sin on 10/27/2022 17:21:57
