Multipolar connector complete 16 poles and ground recessed side outlet PG21

€74.60 Tax included

€61.65 tax excl.

16-pole multipole connectors + grounding, complete with PG21 side outlet, flush panel mounting. They can be used in non-aggressive industrial environments and wherever there is a need for high quality connection.

Part number: CNZ16IO

Representative image for illustrative purposes, the item supplied will correspond to the specifications indicated.

No queries yet, leave the first!


Complete multipole connectors, for panel mounting, 16-pole, grounded. Lateral cable outlet with PG21 thread.

This series of multipole connectors can be used in non-aggressive industrial environments and wherever there is a need for high quality connection. The inserts are made of self-extinguishing thermoplastic resin, according to UL 94V-0, with contacts tin-plated zinc. The assembly is coupled by means of thermoplastic and galvanized steel cams for the enclosures.

Technical characteristics:

  • Manufacturer/Supplier: ILME
  • Part No.: CNZ16IO
  • Series: CNZ, complete connector 16A max - 500Vac.
  • number of poles: 16+Earth.
  • Maximum current: 16A.
  • Maximum voltage: 500V.
  • Conductor cross-section: 0.50 mm2 - 2.50 mm2.
  • Degree of protection: IP66.
  • Cable entry: PG21.
  • Location: Side.
  • Weight:
  • Standard: EN 61984:2009-06

Dimensiones conectores ILME

EsquemaMontajeConectorMultipolar
