Transformer 25VA E:230/400V S:12V IP-00
Transformer 25VA E:230/400V S:12V IP-00

Transformer 25VA E:230-400V S:12V IP-00

€33.03 Tax included

26.85 tax excl.

TR25 2-4/12

Single-phase transformer for command, control and general uses, input voltage 230-400 Vac and output voltage 12Vac. The power of the transformer is 25VA, protection degree IP00.

Reference: TR25 230-400/12

Esquema transformador monofasico 400-230 salida 12

Representative image for illustrative purposes, the item supplied will correspond to the specifications indicated.

1 question about the product
Privacy
Shipments
Returns


Single-phase transformer input 230-400Vac and output 12Vac, power 25VA. Varnished transformer, with degree of protection IP-00. The maximum current supplied is 2.08 A (apparent current).

The main application of this type of transformers is for command and control in industrial automation, and for general applications. They are intended to supply electrical devices where galvanic isolation between circuits is required. They are protected against humidity by means of resin impregnation.

This type of transformers are reversible.

Technical characteristics of the transformer:


  • Reference: TR-25-1 / TR25 230-400/12
  • Type of transformer: Single-phase
  • Transformer primary voltage: 230-400Vac
  • Transformer secondary voltage: 12Vac
  • Transformer rated power: 25 VA
  • Maximum current in the secondary (In): 2.08A
  • Windings: copper wire, thermal class N 200ºC.
  • Insulation: Thermal class B 130ºC.
  • Frequency: 50/60 Hz.
  • Degree of protection: IP-00.
  • Transformer test voltage
    • 5 KV between windings.
    • 2.5 KV between windings and ground.
  • Ambient temperature: Ta= 25ºC.
  • Transformer encapsulation: varnished.
  • Transformer mounting: by means of screws.
  • Certificate: UNE-EN61558

Dim_trafo_monofasico_ip00

  • A: 75mm
  • B: 76mm
  • C: 78 mm
  • D: 49 mm
  • E: 63 mm
  • Diameter: 4 mm
  • Weight: 1 Kg
The transformer is supplied without any type of overload protection, it is mandatory to install them to avoid overloading the transformer. The power and current indicated are apparent, the active current provided by the transformer will depend on the power factor of the connected load.
Professional use material, install in compliance with the regulations in force at the place of installation.

Questions

Question
Bom dia tenho um carregador de bateria auto 6v /12v queimou o transformador será que este é compatível ou teem outro modelo mais adequado Obrigado espero pela vossa resposta
Answer
Bom Dia.

Os transformadores que temos, a saída é 12 Vac, se o seu carregador de bateria tiver um transformador que atenda a essas características, e se adapte ao seu tamanho, será compatível.

Saudações
Custódio on 03/02/2022 07:21:27
