Modular contactor 63A 4Poles open 24Vac

€144.38 Tax included

117.38 tax excl.

CM634NA024

Modular electric contactor with 4 open poles for domestic applications, to control home automation systems, domestic motors, heating, lighting, ventilation and general uses. 4 poles with a capacity of 63A in category AC-1/AC-7a. Coil voltage 24Vac. Size 3 modules (54mm).

Reference: CM63 3M 63A 4NO 24VAC

4-pole contactor electrical diagram



Representative image for illustrative purposes, the item supplied will correspond to the indicated specifications.

1 question about the product
Privacy
Shipments
Returns


Modular contactor with 4 open poles, 63A in category AC-1/AC-7a, the contactor coil voltage is 24Vac. The main application of modular contactors is the control of loads in the domestic environment, it allows the control of domestic, home automation, heating, lighting and air conditioning systems, it can also be used in industrial and general use applications.

Fixing via DIN rail and size 3 modules (54mm).



General characteristics modular contactor:

  • Manufacturer/Supplier: Generic
  • Reference: CM63 3M 63A 4NO 24VAC
  • Contactor rated current in AC1/AC7a: 63A.
  • number of contacts (poles): 4.
  • Contact status: Normally open NA.
  • Coil voltage: 24Vac. 50/60 Hz.
  • Operating voltage in main contacts (Un): 440Vac.
  • Insulation voltage (Ui) : 500V.
  • Maximum contactor power in AC1/AC7a 230Vac: 40 Kw.
  • Maximum contactor power in AC3/AC7b 230Vac: 15 Kw.
  • Electrical life (category AC1, AC7a): 150,000 cycles.
  • Electrical life (category AC3, AC7b): 150,000 cycles.
  • Width size: 54mm (3 modules).
  • Regulations: IEC61095/EN60947-4-1.



Modular contactor dimensions 63A 4 poles


Material for professional use, install in compliance with the regulations in force at the installation site.

Questions

Question
Cerco contattore a binario Din, da 63A, con 4 poli principali NA e almeno 1 contatto ausiliario NC; bobina di alimentazione 230V. Costo e disponibilità. Grazie, Quinto Scicchitano (Titolare azienda operante nel settore elettrico)
Answer
Buon pomeriggio.

Inviamo link del materiale richiesto

https://adajusa.it/it/contattori-modulari/2838-contattore-modulare-63a-4pannelli-aperti-230vac-8435532828389.html

https://adajusa.it/it/contattori-modulari/3125-contattore-modulare-ausiliario-contatti-telecamera-1no1nc-8435532831259.html


Tuttavia, verifica che soddisfi le tue specifiche.

Saluti

Adajusa
Quinto Scicchitano on 02/01/2023 18:57:05
