Single-phase autotransformer 5000VA 125/220Vac IP-00

Special manufacturing material
€222.58 Tax included

€180.96 tax excl.

AT-5000

autotransformer reversible single-phase of 5000VA, which allows voltage adaptation between 125 and 220Vac.

It allows to adapt the tension in small machinery and appliances in an economical way.

Reference: AT-5000

Esquema autotransformador 125-220V

1 question about the product
Privacy
Shipments
Returns


Single-phase self-transformer for voltage change, reversible, intended for voltage change. They are indicated when it is necessary to adapt the voltage from 125V to 220V / 220V to 125V., or 230 to 400v, in an economical way, without galvanic separation. Its usual field of application is the use in small machinery and appliances.

Manufactured with low loss magnetic sheet and copper wire windings, providing high performance.

Technical details:

  • Ref: AT-5000
  • Transformation ratio: 125/220 Vac Reversible IP-00.
  • Power: 5000VA.
  • Frequency: 50/60Hz.
  • Windings: Thermal class N 200oC.
  • Test voltage: 3KV between mass.
  • Insulators: Thermal class F 155oC and H 180oC.
  • Protection: IP-00
  • Ambient temperature: TA-25oC.
  • Cooling: ANAN (Air natural).
  • Certificate: UNE-EN 61558.
  • Dimensions (width/background/height): 108x104x105mm

Questions

Question
En mi casa tengo un voltaje de 190 , pero va bajando a partir de la tarde a 140w , hay fluctuaciones de corriente, y nunca llega a los 220w , con el autotransformador de 125/250 puedo regularizar el fluido a esos 220w que es lo normal en la vivienda
Answer
Buenos días.

 Entnedemos que la tensión de su vivienda es de 230 Vac, Con un transformador no sería posible, necesitaría un estabilizador de tensión ajustado a la potencia máxima. Un estabilizador de 5KVA soporta una carga máxima de 3500 W.


  • Rango de tensión de entrada: Monofásica 160V-270V 50Hz  -  230Vac ±25% (ajustable hasta ±30%) + Tierra
  • Rango de tensión de salida: Monofásica a 230V, 50Hz/60Hz con toma de tierra  -  230Vac ± 2% (ajustable) + Tierra
Saludos

Adajusa
Antonio on 07/01/2023 20:04:53
