polyurethane Hose with textile reinforcement 7.5x10mm Roll 25m

Flexible polyurethane tube with polyester fiber textile reinforcement for pneumatic applications, measurement 7.5x10mm. 25 meter roll in blue. Hose for connecting machinery in pneumatic installations. High-performance Hose , easy handling, high flexibility and low deformation, great resistance and durability.


Multilayer tube, composed of an inner layer and an outer layer of 85 Shore A ether-based polyurethane resistant to hydrolysis and microbial attack, has a high modulus PET wire weave woven into a rhombic mesh for maximum sealing . The outer layer is antistatic and lubricated for better sliding. Optimum abrasion resistance, optimal flexibility and elasticity, resistant to pressures higher than the single-layer version and excellent water resistance.


This type of hose is suitable for use in pneumatic applications, the industrial sector and various applications such as automation, vacuum, industrial machine tools, and where resistance to hydrolysis is required. It is especially recommended for the agricultural sector, bodywork and distribution workshops.

Characteristics:

• Manufacturer/Supplier: Mebra / Aignep
• Reference: 185CRT7.5X10
• Measurement: 7.5x10mm
• Quantity: Roll 25m
• Available colors: Blue
• Outer diameter: 10mm
• Inner diameter: 7.5mm
• Thickness: 1.25mm
• Temperature: -40ºC to +60ºC
• Burst pressure safety factor: 3:1
• Tolerances:

  ±0.15 in wall thickness
  ±0.15 in outer Ø
  ±0.15 inside Ø



Material for professional use, install in compliance with the regulations in force at the installation site.
