Cylinder 100x50 double effect - Metal Work

€211.29 Tax included

€174.62 tax excl.

Free shipping!

Pneumatic cylinder diameter 100x50 double magnetic effect. With pneumatic cushioning, aluminum jacket and chromed steel stem.
Reference: 1213A10050AN
Esquema actuador neumatido doble efecto con amortiguación

Logotipo Metal Work

Representative image for illustrative purposes, the article supplied will correspond to the specifications indicated.

No queries yet, leave the first!


Pneumatic cylinder diameter 100 mm stroke 50mm, double effect with pneumatic damping and ready to install magnetic detectors. The pneumatic cylinder is manufactured according to ISO 15552 (Ex ISO 6431), with an aluminium jacket. Stem in chromed steel. Wide range of accessories for pneumatic cylinder mounting.

Technical characteristics of the pneumatic cylinder:

  • Manufacturer: Metal Work.
  • Manufacturer's Reference: 12131000050 (121A1000050 – 1211000050)
  • Diameter and stroke: 100x50 mm.
  • Type: Double-effect pneumatic cylinder.
  • Damping: pneumatic.
  • Fluid type: Air with or without lubrication.
  • Manufacturing standard: ISO 15552 (EX ISO 6431)
  • Maximum operating pressure: 10 Bar.
  • Type of gaskets: NBR.
  • Operating temperature: -10oC to +70oC.
  • Type of construction: Chromed steel shank, aluminum shirt.
  • Air inlet thread size: G 1/2".
  • Cylinder stem thread: M20x1.5
  • Weight: 4.34 Kg.
  • Theoretical maximum force that can develop the cylinder at thrust:

Pressure 5 kg/cm2: 251.3 Kg.

Pressure 6 kg/cm2: 301.6 Kg.

Pressure 7 kg/cm2: 351.9 Kg.

  • Theoretical maximum force that can develop the cylinder to traction:

Pressure 5 kg/cm2: 226.8 Kg.

Pressure 6 kg/cm2: 272.1 Kg.

Pressure 7 kg/cm2: 317.5 Kg.

Dimensines cilindro neumático ISO diámetro 100x50
Material for professional use, install in compliance with the regulations in force at the place of installation.

To expand the information you can download the data sheet by clicking on the tab "Attachments"
