MCB circuit breaker 3 poles 32A (3x32A) - Hyundai Electric

€22.82 Tax included

€18.86 tax excl.

MCB circuit breaker 3 poles 32A curve C,for protection against short circuits and overloads in three-phase installations. With an breaking capacity of 6000A. Protects both drivers. It can be used in installations and assembly up to 500VAC.

Reference: HGD63-M3P032C

Esquema eléctrico margnetotérmico 2 polos

No queries yet, leave the first!


MCB circuit breaker 3 poles 32A 6kA curve "C", for protection against short circuits and overloads in three-phase installations. With an assigned cutting power of 6kA, active protection of the poles with status indication. Made of fireproof thermoplastic material. Manufactured according to reference regulations IEC/EN60898-1.

Ideal for use in both tertiary or industrial installations as well as in machine automation cabinets. High reliability and performance allowing a high number of duty cycles.

As main features of this product range we can review:

  • Compact design and structure.
  • 13 plates in the extinguishing chamber for effective arc cooling.
  • Free firing mechanism. The switch fires even if maintenance is forced in the on position (ON).
  • Visual status indication.
  • Supports mounting a large number of accessories.

Technical details:

  • Manufacturer/Supplier: Hyundai Electric.
  • Manufacturer's Reference: HGD63-M3P032C.
  • Nominal MCB circuit breaker intensity (In): 32A.
  • Number of poles: 3 (3x32A).
  • Step: 3 modules.
  • Cutting power (Icn): 6000A (6kA) (Ics-100% icn).
  • Maximum operating voltage (Eu): 240/415Vac, 50/60Hz.
  • Characteristic curve: C.
  • Assigned insulation voltage (Ui): 500Vac.
  • Rated pulse resistance voltage (Uimp): 4 KV.
  • Dielectric resistance: 2.5kV.
  • Protection: IP20.
  • Enduring: ≥10000/20000.
  • Operating temperature: -5oC... +55oC.
  • Humidity: 95% RH.
  • Energy limitation class: Class 3.
  • Terminal type: Screw tightening jaw.
  • Maximum terminal capacity: 25mm2.
  • Maximum tightening torque: 2 Nm.
  • Weight: 0.150 Kg.
  • Dimensions (mm): 80.5x71x53.1 mm
  • Mounting position: Vertical/Horizontal.
  • Housing and cover material: Ignifugo molded thermoplastic.
  • Supports mounting of auxiliary elements: SI.
  • Regulations: EC; IEC/EN 60898-1.

Dimensiones magnetotermicos HCG63N
